Hastelloy C276 Socket Weld Cross
| Specification | Details |
|---|---|
| Product Name | Hastelloy C276 Socket Weld Cross |
| Material Grade | Hastelloy C276 / Alloy C276 |
| UNS Designation | UNS N10276 |
| Werkstoff Number | W.Nr. 2.4819 |
| Material Type | Nickel-Chromium-Molybdenum-Tungsten Alloy |
| Fitting Type | Socket Weld Cross |
| Cross Type | Equal Cross / Reducing Cross |
| Manufacturing Type | Forged / Hot Forged / Precision Machined |
| Fitting Standard | ASTM B366 / ASME SB366, as applicable |
| Dimensional Standard | ASME B16.11 |
| Size Range | 1/8″ to 4″ NPS or As per Customer Requirement |
| Pressure Class | Class 3000 / 6000 / 9000, as applicable |
| Connection Type | Socket Weld |
| End Connection | Socket Weld |
| Surface Finish | Bright / Pickled / Machined / Polished / Passivated / As Specified |
| Heat Treatment | Solution Annealed / As per Applicable Material Specification |
| Dimensions | As per ASME B16.11 and Customer Requirements |
| MTC | EN 10204 3.1 / 3.2 |
| Testing | Chemical / Mechanical / Dimensional / Hardness / Visual / PMI and Other Tests as Required |
| Tensile Strength | As per Applicable Hastelloy C276 Material Specification and Condition |
| Yield Strength | As per Applicable Hastelloy C276 Material Specification and Condition |
| Elongation | As per Applicable Material Standard |
| Density | Approximately 8.89 g/cm³ |
| Melting Range | Approximately 1325–1370°C |
| Corrosion Resistance | Excellent resistance to general and aggressive corrosion in demanding environments |
| Pitting Resistance | Excellent resistance to pitting and crevice corrosion |
| Crevice Corrosion Resistance | Excellent resistance to crevice corrosion |
| Chloride Resistance | Excellent resistance to chloride-containing environments |
| Stress-Corrosion Resistance | Excellent resistance to chloride-induced stress-corrosion cracking |
| Acid Resistance | Excellent resistance to selected oxidizing and reducing acids |
| Oxidation Resistance | Good resistance to oxidation under suitable service conditions |
| High-Temperature Performance | Good mechanical stability and corrosion resistance at elevated temperatures |
| Welding | Suitable for socket-welded piping systems using appropriate nickel-alloy welding procedures |
| Fabrication | Suitable for precision machining and specialized fabrication |
| Dimensional Accuracy | Precision dimensions according to ASME B16.11 and applicable requirements |
| Available Forms | Equal Socket Weld Cross / Reducing Socket Weld Cross / Forged Socket Weld Cross |
| Customization | Size, Cross Type, Branch Dimensions, Pressure Class, Finish, Testing and Documentation |
| Inspection | Dimensional, Visual and Material Inspection as Required |
| Marking | Size, Grade, Standard and Heat/Batch Identification as Applicable |
| Origin | European / American / Japanese / Korean and Other Approved Origins |
| Export Supply | Worldwide Hastelloy C276 Socket Weld Cross Export Supply |
| Exporter Support | Technical Specifications, Inspection, Certification, Export Packing, Documentation and International Shipment Coordination |
| Applications | Chemical Processing, Petrochemical, Oil & Gas, Pharmaceutical, Pollution Control, Power Generation, Marine, Wastewater Treatment and High-Performance Process Piping |
1. Hastelloy C276 Socket Weld Cross – Common Types
| Type | Description |
|---|---|
| Equal Socket Weld Cross | Four outlets of the same nominal size, suitable for creating four-way branch connections in piping systems. |
| Reducing Socket Weld Cross | Features different outlet or branch sizes for connecting pipes of different diameters. |
| Forged Socket Weld Cross | Manufactured through forging for good strength, structural integrity and dimensional consistency. |
| Class 3000 Socket Weld Cross | Suitable for piping applications requiring Class 3000 pressure-rated fittings. |
| Class 6000 Socket Weld Cross | Designed for higher-pressure piping systems requiring Class 6000 fittings. |
| Class 9000 Socket Weld Cross | Used for specialized high-pressure applications requiring Class 9000 fittings. |
| Precision Machined Cross | Precision-machined construction provides accurate dimensions and reliable socket fit-up. |
| Customized Socket Weld Cross | Supplied with customized sizes, branch dimensions, pressure classes, finishes, testing and documentation. |
2. Hastelloy C276 Socket Weld Elbow – Technical Specifications
| Specification | Details |
|---|---|
| Product Name | Hastelloy C276 Socket Weld Cross |
| Material Grade | Hastelloy C276 / Alloy C276 |
| UNS Designation | UNS N10276 |
| Werkstoff Number | W.Nr. 2.4819 |
| Material Type | Nickel-Chromium-Molybdenum-Tungsten Alloy |
| Fitting Type | Socket Weld Cross |
| Cross Type | Equal Cross / Reducing Cross |
| Manufacturing Type | Forged / Hot Forged / Precision Machined |
| Fitting Standard | ASTM B366 / ASME SB366, as applicable |
| Dimensional Standard | ASME B16.11 |
| Size Range | 1/8″ to 4″ NPS or As per Customer Requirement |
| Pressure Class | Class 3000 / 6000 / 9000, as applicable |
| Connection Type | Socket Weld |
| End Connection | Socket Weld |
| Surface Finish | Bright / Pickled / Machined / Polished / Passivated / As Specified |
| Heat Treatment | Solution Annealed / As per Applicable Material Specification |
| Dimensions | As per ASME B16.11 and Customer Requirements |
| MTC | EN 10204 3.1 / 3.2 |
| Testing | Chemical / Mechanical / Dimensional / Hardness / Visual / PMI and Other Tests as Required |
| Tensile Strength | As per Applicable Hastelloy C276 Material Specification and Condition |
| Yield Strength | As per Applicable Hastelloy C276 Material Specification and Condition |
| Elongation | As per Applicable Material Standard |
| Density | Approximately 8.89 g/cm³ |
| Melting Range | Approximately 1325–1370°C |
| Corrosion Resistance | Excellent resistance to general and aggressive corrosion |
| Pitting Resistance | Excellent resistance to pitting and localized corrosion |
| Crevice Corrosion Resistance | Excellent resistance to crevice corrosion |
| Chloride Resistance | Excellent resistance to chloride-containing environments |
| Stress-Corrosion Resistance | Excellent resistance to chloride-induced stress-corrosion cracking |
| Acid Resistance | Excellent resistance to selected oxidizing and reducing acids |
| Oxidation Resistance | Good resistance to oxidation under suitable service conditions |
| High-Temperature Performance | Good mechanical stability and corrosion resistance at elevated temperatures |
| Welding | Suitable for socket-welded piping systems using appropriate nickel-alloy welding procedures |
| Fabrication | Suitable for precision machining and specialized fabrication |
| Dimensional Accuracy | Precision dimensions according to ASME B16.11 and applicable requirements |
| Available Forms | Equal Socket Weld Cross / Reducing Socket Weld Cross / Forged Socket Weld Cross |
| Customization | Size, Cross Type, Branch Dimensions, Pressure Class, Finish, Testing and Documentation |
| Inspection | Dimensional, Visual and Material Inspection as Required |
| Marking | Size, Grade, Standard and Heat/Batch Identification as Applicable |
| Origin | European / American / Japanese / Korean and Other Approved Origins |
| Export Supply | Worldwide Hastelloy C276 Socket Weld Cross Export Supply |
| Exporter Support | Technical Specifications, Inspection, Certification, Export Packing, Documentation and International Shipment Coordination |
| Applications | Chemical Processing, Petrochemical, Oil & Gas, Pharmaceutical, Pollution Control, Power Generation, Marine, Wastewater Treatment and High-Performance Process Piping |
3. Hastelloy C276 Socket Weld Cross – Supply & Export Details
| Supply Parameter | Available Options |
|---|---|
| Material | Hastelloy C276 / Alloy C276 / UNS N10276 |
| Cross Configuration | Equal Cross / Reducing Cross |
| Size | 1/8″ to 4″ NPS or As per Requirement |
| Pressure Classes | Class 3000 / 6000 / 9000 |
| Manufacturing | Forged / Hot Forged / Precision Machined |
| Connection | Socket Weld |
| Surface Finish | Bright / Pickled / Machined / Polished / Passivated |
| Heat Treatment | Solution Annealed / As Required |
| Testing | Chemical / Mechanical / Dimensional / Visual / Hardness / PMI / NDT as Required |
| Inspection | Dimensional, Visual and Material Inspection |
| Certification | EN 10204 3.1 / 3.2 |
| Material Traceability | Heat Number, Grade and Batch Identification |
| Marking | Size, Grade, Standard and Heat/Batch Identification |
| Third-Party Inspection | Available as per Customer Requirement |
| Customization | Size, Branch Dimensions, Pressure Class, Finish, Testing and Documentation |
| Packing | Export-Worthy / Seaworthy Protective Packaging |
| Origin | European / American / Japanese / Korean and Other Approved Origins |
| Exporter Support | Technical Specifications, Inspection, Certification, Packing and Shipment Coordination |
| Export Supply | Worldwide Hastelloy C276 Socket Weld Cross Supply |
| Applications | Chemical, Petrochemical, Oil & Gas, Pharmaceutical, Marine, Power Generation, Pollution Control, Wastewater Treatment and Industrial Process Piping |
Most Common Types Of Hastelloy C276 Socket Weld Cross
| Type | Description |
|---|---|
| Hastelloy C276 Equal Socket Weld Cross | Features four outlets of the same nominal size and is used for four-way branch connections in piping systems. |
| Hastelloy C276 Reducing Socket Weld Cross | Features different outlet sizes and is used where branch connections require different pipe diameters. |
| Hastelloy C276 Forged Socket Weld Cross | Manufactured by forging to provide good mechanical strength, structural integrity and dimensional consistency. |
| Hastelloy C276 Class 3000 Cross | Suitable for piping systems requiring Class 3000 pressure-rated socket weld fittings. |
| Hastelloy C276 Class 6000 Cross | Designed for higher-pressure applications requiring Class 6000 socket weld fittings. |
| Hastelloy C276 Class 9000 Cross | Used for specialized high-pressure piping applications requiring Class 9000 fittings. |
| Hastelloy C276 Precision Machined Cross | Precision-machined construction provides accurate socket dimensions and reliable pipe fit-up. |
| Hastelloy C276 Customized Socket Weld Cross | Available with customized size, branch dimensions, pressure class, surface finish, testing and documentation according to project requirements. |
Why Should You Buy Hastelloy C276 Socket Weld Crosses from MetalX Nickel & Alloys?
- Experienced Hastelloy C276 Socket Weld Cross Supplier & Exporter serving international buyers, importers, distributors, EPC contractors, stockholders, traders and industrial end users.
- 20+ Years of Nickel Alloy Industry Experience in supplying and exporting corrosion-resistant, high-performance and specialty nickel alloy products across the UAE, Saudi Arabia, Qatar, Oman, Kuwait, Bahrain, Africa, Europe, Asia and other global markets.
- Specialized Hastelloy C276 Socket Weld Cross Exporter offering Hastelloy C276 / Alloy C276 / UNS N10276 / W.Nr. 2.4819 Socket Weld Crosses according to applicable international standards and customer requirements.
- Global Hastelloy C276 Exporter Network with access to reputed nickel alloy mills, manufacturers, authorized suppliers and approved stockholders across the USA, Europe, Japan, South Korea and other major international supply markets.
- Reliable Hastelloy C276 Socket Weld Cross Supplier providing nickel-chromium-molybdenum-tungsten alloy fittings for applications requiring excellent corrosion resistance, pitting and crevice corrosion resistance, chloride resistance, acid resistance and reliable mechanical strength.
- Wide Nickel Alloy Fittings Range including Hastelloy C276 Socket Weld Elbows, Hastelloy C276 Socket Weld Tees, Hastelloy C276 Socket Weld Couplings, Hastelloy C276 Socket Weld Unions, Hastelloy C276 Socket Weld Crosses, Hastelloy C276 Socket Weld Caps and Hastelloy C276 Socket Weld Reducers.
- Equal & Reducing Cross Supply – Available in Equal Cross and Reducing Cross configurations for different branch connection and piping requirements.
| Key Feature | Details |
|---|---|
| Excellent Corrosion Resistance | Provides excellent resistance to severe general corrosion in aggressive industrial environments. |
| Pitting & Crevice Corrosion Resistance | Offers strong resistance to localized corrosion, including pitting and crevice attack. |
| Chloride Resistance | Suitable for chloride-containing process environments and demanding marine applications. |
| Stress-Corrosion Cracking Resistance | Provides excellent resistance to chloride-induced stress-corrosion cracking. |
| Oxidizing & Reducing Media Resistance | Performs reliably in a broad range of oxidizing and reducing chemical environments. |
| High Mechanical Strength | Provides good mechanical strength, durability and structural stability for critical piping systems. |
| Four-Way Branch Connection | Provides four connection points for complex piping layouts and branch arrangements. |
| Compact Socket Weld Design | Offers a compact and reliable connection, particularly useful for smaller-diameter piping systems. |
| Forged Construction | Forged construction supports structural integrity, strength and dimensional consistency. |
| Multiple Pressure Classes | Available in Class 3000, 6000 and 9000 configurations, subject to applicable requirements. |
| Equal & Reducing Options | Available as equal or reducing cross configurations for different piping requirements. |
| Precision Dimensions | Accurate socket dimensions support proper pipe fit-up and reliable installation. |
| Custom Manufacturing | Size, branch dimensions, pressure class, finish, testing and documentation can be customized. |
| Inspection & Certification | MTC, PMI, dimensional inspection and other quality documents can be supplied as required. |
| Wide Industrial Applications | Suitable for chemical, petrochemical, pharmaceutical, oil & gas, power, marine, pollution-control and process industries. |
| Export-Ready Supply | Available with material traceability, identification, protective packaging and export documentation. |
| Specification | Details |
|---|---|
| Product Name | Hastelloy C276 Socket Weld Cross |
| Material Grade | Hastelloy C276 / Alloy C276 |
| UNS Designation | UNS N10276 |
| Werkstoff Number | W.Nr. 2.4819 |
| Material Type | Nickel-Molybdenum-Chromium-Tungsten Alloy |
| Chemical Composition | Nickel Balance, Chromium approximately 14.5–16.5%, Molybdenum approximately 15–17%, Tungsten approximately 3–4.5%, Iron approximately 4–7%, Carbon 0.01% max |
| Fitting Type | Socket Weld Cross |
| Cross Type | Equal Cross / Reducing Cross |
| Manufacturing Type | Forged / Hot Forged / Precision Machined |
| Material Standard | ASTM B366 / ASME SB366, as applicable |
| Dimensional Standard | ASME B16.11 |
| Size Range | Typically 1/8″ to 4″ NPS or As per Customer Requirement |
| Pressure Class | Class 3000 / 6000 / 9000, as applicable |
| Connection Type | Socket Weld |
| End Connection | Socket Weld |
| Shape | Four-Way Cross / 90° Branch Connection |
| Surface Finish | Machined / Pickled / Passivated / Polished / As Specified |
| Heat Treatment | Solution Annealed / As per Applicable Material Specification |
| Dimensions | As per ASME B16.11 and Customer Requirements |
| MTC | EN 10204 3.1 / 3.2, as required |
| Testing | Chemical / Mechanical / Dimensional / Hardness / Visual / PMI and Other Tests as Required |
| Inspection | Dimensional, Visual and Material Inspection as Required |
| Tensile Strength | As per Applicable Hastelloy C276 Material Specification and Condition |
| Yield Strength | As per Applicable Hastelloy C276 Material Specification and Condition |
| Elongation | As per Applicable Material Standard |
| Density | Approximately 8.89 g/cm³ |
| Melting Range | Approximately 1325–1370°C |
| Corrosion Resistance | Excellent resistance to general corrosion and aggressive chemical environments |
| Pitting Resistance | Excellent resistance to pitting and localized corrosion |
| Crevice Corrosion Resistance | Excellent resistance to crevice corrosion |
| Chloride Resistance | Excellent resistance to chloride-containing environments |
| Stress-Corrosion Resistance | Excellent resistance to chloride-induced stress-corrosion cracking |
| Acid Resistance | Excellent resistance to selected oxidizing and reducing acids |
| High-Temperature Performance | Good mechanical stability and corrosion resistance under suitable elevated-temperature conditions |
| Welding | Suitable for socket-welded piping systems using appropriate nickel-alloy welding procedures |
| Fabrication | Suitable for precision machining and specialized fabrication |
| Dimensional Accuracy | Precision dimensions according to ASME B16.11 and applicable requirements |
| Available Forms | Equal Socket Weld Cross / Reducing Socket Weld Cross / Forged Socket Weld Cross |
| Customization | Size, Cross Type, Branch Dimensions, Pressure Class, Finish, Testing and Documentation |
| Marking | Size, Grade, Standard and Heat/Batch Identification as Applicable |
| Origin | European / American / Japanese / Korean and Other Approved Origins |
| Export Supply | Worldwide Hastelloy C276 Socket Weld Cross Export Supply |
| Exporter Support | Technical Specifications, Inspection, Certification, Export Packing, Documentation and International Shipment Coordination |
| Applications | Chemical Processing, Petrochemical, Oil & Gas, Pharmaceutical, Pollution Control, Power Generation, Marine, Wastewater Treatment and High-Performance Process Piping |
1. What is a Hastelloy C276 Socket Weld Cross?
A Hastelloy C276 Socket Weld Cross is a forged nickel-alloy piping fitting used to create a four-way connection between piping sections. It uses socket weld connections and is designed for demanding corrosive service conditions.
2. What material is used for Hastelloy C276 Socket Weld Cross?
It is manufactured from Hastelloy C276 / Alloy C276, designated UNS N10276 and W.Nr. 2.4819. The alloy provides excellent resistance to aggressive chemical environments.
3. What types of Hastelloy C276 Socket Weld Cross are available?
The common configurations include Equal Socket Weld Cross and Reducing Socket Weld Cross. Forged and precision-machined versions can also be supplied according to project requirements.
4. What sizes and pressure classes are available?
Hastelloy C276 Socket Weld Crosses are commonly available from 1/8″ to 4″ NPS, subject to requirements. Pressure classes generally include Class 3000, Class 6000 and Class 9000, depending on size and applicable specifications.
5. Which standards apply to Hastelloy C276 Socket Weld Cross?
The fittings can be supplied according to ASME B16.11 for dimensional requirements and ASTM B366 / ASME SB366 for applicable material and fitting requirements.
6. Where are Hastelloy C276 Socket Weld Crosses used?
They are commonly used in chemical processing, petrochemical, oil & gas, pharmaceutical, pollution control, power generation, marine, wastewater treatment and high-performance process piping systems where high corrosion resistance is required.
