Hastelloy C22 Tee
| Specification Hastelloy C22 Tee Details | |
|---|---|
| Product Name | Hastelloy C22 Tee |
| Material Grade | Hastelloy C22 / Alloy C22 |
| UNS Designation | UNS N06022 |
| Werkstoff Number | W.Nr. 2.4602 |
| Material Type | Nickel-Chromium-Molybdenum-Tungsten Alloy |
| Chemical Composition | Nickel Balance, Chromium 20–22.5%, Molybdenum 12.5–14.5%, Tungsten 2.5–3.5%, Iron 2–6%, Cobalt 2.5% max, Carbon 0.015% max, Vanadium 0.35% max |
| Manufacturing Type | Seamless / Welded / Hot Formed / Cold Formed |
| Fitting Standard | ASTM B366 / ASME SB366 |
| Dimensional Standard | ASME B16.9 |
| Tee Type | Equal Tee / Reducing Tee |
| Size | NPS 1/2 to NPS 48 or as required |
| Outside Diameter | As per ASME B16.9 / Customer Requirement |
| Wall Thickness | SCH 5S, 10S, 10, 40S, 40, 80S, 80, 100, 120, 140, 160, XXS or as required |
| Branch Size | Equal / Reduced Branch as specified |
| End Type | Butt Weld / Beveled End / Customized |
| Surface Finish | Mill Finish / Pickled / Annealed / Polished / Customized |
| Heat Treatment | Solution Annealed / Rapidly Quenched as applicable |
| MTC | EN 10204 3.1 / 3.2 |
| Testing | Chemical, Mechanical, Dimensional, Visual, Hydrostatic, PMI and NDT as specified |
| Tensile Strength | Minimum approximately 690 MPa |
| Yield Strength | Minimum approximately 283 MPa |
| Elongation | Minimum approximately 40% |
| Density | Approximately 8.69 g/cm³ |
| Melting Range | Approximately 1357–1399°C |
| Corrosion Resistance | Excellent resistance to pitting, crevice corrosion, stress-corrosion cracking and oxidizing/reducing environments |
| High-Temperature Resistance | Excellent resistance to oxidation and corrosive environments at elevated temperatures |
| Chemical Resistance | Excellent resistance to wet chlorine, hypochlorites, ferric chloride and various aggressive chemicals |
| Welding | Excellent weldability using suitable Hastelloy C22-compatible welding procedures |
| Filler Metal | ERNiCrMo-10 / Alloy C22 compatible filler |
| Welding Electrode | ENiCrMo-10 |
| Available Form | Equal Tee / Reducing Tee |
| Customization | Size, Schedule, Branch Size, End Preparation, Finish, Testing and Documentation |
| Origin | European / American / Japanese / Korean and other approved origins |
| Export Supply | Worldwide Export Supply |
| Exporter Support | Technical specification, inspection, certification, export packing and international shipment coordination |
| Applications | Chemical Processing, Pharmaceutical, Petrochemical, Pollution Control, Waste Treatment, FGD Systems, Pulp & Paper, Marine and Process Industries |
Hastelloy C22 Tee – Equal & Reducing Tee Sizes
| Run Size | Branch Size | Tee Type | Outside Diameter |
|---|---|---|---|
| 1/2″ | 1/2″ | Equal Tee | 21.34 mm |
| 3/4″ | 3/4″ | Equal Tee | 26.67 mm |
| 1″ | 1″ | Equal Tee | 33.40 mm |
| 1-1/4″ | 1-1/4″ | Equal Tee | 42.16 mm |
| 1-1/2″ | 1-1/2″ | Equal Tee | 48.26 mm |
| 2″ | 2″ | Equal Tee | 60.33 mm |
| 2-1/2″ | 2-1/2″ | Equal Tee | 73.03 mm |
| 3″ | 3″ | Equal Tee | 88.90 mm |
| 4″ | 4″ | Equal Tee | 114.30 mm |
| 6″ | 6″ | Equal Tee | 168.28 mm |
| 8″ | 8″ | Equal Tee | 219.08 mm |
| 10″ | 10″ | Equal Tee | 273.05 mm |
| 12″ | 12″ | Equal Tee | 323.85 mm |
| 2″ | 1″ | Reducing Tee | 60.33 / 33.40 mm |
| 3″ | 2″ | Reducing Tee | 88.90 / 60.33 mm |
| 4″ | 2″ | Reducing Tee | 114.30 / 60.33 mm |
| 4″ | 3″ | Reducing Tee | 114.30 / 88.90 mm |
| 6″ | 4″ | Reducing Tee | 168.28 / 114.30 mm |
| 8″ | 6″ | Reducing Tee | 219.08 / 168.28 mm |
| 10″ | 8″ | Reducing Tee | 273.05 / 219.08 mm |
| 12″ | 10″ | Reducing Tee | 323.85 / 273.05 mm |
Hastelloy C22 Tee – Standard Dimensions
| NPS | Outside Diameter (mm) | Outside Diameter (in.) | Typical Schedule Range |
|---|---|---|---|
| 1/2″ | 21.34 | 0.840 | SCH 5S–XXS |
| 3/4″ | 26.67 | 1.050 | SCH 5S–XXS |
| 1″ | 33.40 | 1.315 | SCH 5S–XXS |
| 1-1/4″ | 42.16 | 1.660 | SCH 5S–XXS |
| 1-1/2″ | 48.26 | 1.900 | SCH 5S–XXS |
| 2″ | 60.33 | 2.375 | SCH 5S–XXS |
| 2-1/2″ | 73.03 | 2.875 | SCH 5S–XXS |
| 3″ | 88.90 | 3.500 | SCH 5S–XXS |
| 4″ | 114.30 | 4.500 | SCH 5S–XXS |
| 5″ | 141.30 | 5.563 | SCH 5S–XXS |
| 6″ | 168.28 | 6.625 | SCH 5S–XXS |
| 8″ | 219.08 | 8.625 | SCH 5S–XXS |
| 10″ | 273.05 | 10.750 | SCH 5S–XXS |
| 12″ | 323.85 | 12.750 | SCH 5S–XXS |
| 14″ | 355.60 | 14.000 | SCH 5S–XXS |
| 16″ | 406.40 | 16.000 | SCH 5S–XXS |
| 18″ | 457.20 | 18.000 | SCH 5S–XXS |
| 20″ | 508.00 | 20.000 | SCH 5S–XXS |
| 24″ | 609.60 | 24.000 | SCH 5S–XXS |
| 30″ | 762.00 | 30.000 | As Required |
| 36″ | 914.40 | 36.000 | As Required |
| 42″ | 1066.80 | 42.000 | As Required |
| 48″ | 1219.20 | 48.000 | As Required |
Hastelloy C22 Tee – Size & Type Chart
| Size Range | Tee Type | Available Finish | Supply Condition | End Connection |
|---|---|---|---|---|
| 1/2″–2″ | Equal / Reducing | Bright / Pickled / Polished | Solution Annealed | Butt Weld / Customized |
| 2-1/2″–4″ | Equal / Reducing | Mill / Pickled / Polished | Solution Annealed | Butt Weld |
| 5″–8″ | Equal / Reducing | Mill / Pickled / Machined | Solution Annealed | Butt Weld |
| 10″–12″ | Equal / Reducing | Mill / Pickled / Machined | Solution Annealed | Butt Weld |
| 14″–18″ | Equal / Reducing | Mill / Machined | Solution Annealed | Butt Weld |
| 20″–24″ | Equal / Reducing | Mill / Machined | Solution Annealed | Butt Weld |
| 30″–36″ | Equal / Reducing | Mill / Machined | Solution Annealed | Butt Weld |
| 42″–48″ | Equal / Reducing | Mill / Machined | Solution Annealed | Butt Weld |
Why Should You Buy Hastelloy C22 Tees from Metalx Nickel & Alloys?
- Experienced Hastelloy C22 Tee Supplier & Exporter serving international buyers, distributors, EPC contractors, stockholders and industrial end users.
- 20+ Years of Nickel Alloy Industry Experience in supplying corrosion-resistant and high-performance alloy products to customers across the UAE, Saudi Arabia, Africa and other global markets.
- Specialized Hastelloy C22 Exporter offering Hastelloy C22 / UNS N06022 Tees for demanding chemical, petrochemical and process applications.
- Global Sourcing Network with access to reputed nickel alloy mills, manufacturers and approved stockholders across Europe, USA, Japan and other major supply markets.
- Wide Nickel Alloy Fittings Range including Hastelloy C22, Hastelloy C276, Hastelloy B3, Inconel, Incoloy, Monel and other specialized nickel alloy fittings.
- Ready Stock Availability for selected Hastelloy C22 Tee sizes, subject to current stock and availability.
- Custom Hastelloy C22 Tee Supply according to customer drawings, size, schedule, wall thickness and branch dimensions.
- Equal & Reducing Tee Supply for standard and specialized industrial piping requirements.
- ASTM / ASME Specification Supply according to applicable requirements, including ASTM B366 / ASME SB366, where applicable.
- ASME B16.9 Dimensional Compliance can be supplied where applicable to the fitting configuration.
- MTC with Quotation – Material Test Certificates and relevant technical documentation can be provided with export quotations and orders.
- EN 10204 3.1 / 3.2 Certification available according to the purchase order, project specification and inspection requirements.
- Third-Party Inspection Support can be coordinated through approved inspection agencies for international export orders.
- Chemical, Mechanical & Dimensional Testing can be arranged according to applicable standards and customer specifications.
- Visual & Hardness Testing Support can be arranged where required by the applicable specification or purchase order.
- Custom Surface Finish – Mill finish or other specified finishes can be supplied according to requirements.
- Export-Ready Packing designed to protect Hastelloy C22 Tees during handling, storage and international transportation.
- Worldwide Hastelloy C22 Tee Exporter serving buyers across the Middle East, Africa, Asia, Europe and other international markets.
- Competitive Export Pricing for bulk quantities, project orders, distributors, importers, traders and international stockholders.
- Hastelloy C22 Tee Export Support for EPC contractors, chemical plants, petrochemical companies, pharmaceutical industries, pollution-control facilities, waste-treatment plants and specialized engineering buyers.
- Technical Support from Export Enquiry to Shipment covering grade, size, schedule, wall thickness, branch dimensions, testing, certification and packing requirements.
- Material Traceability with appropriate identification, certification and quality documentation for export projects.
- Data Sheets & Technical Documentation can be supplied according to customer requirements and project specifications.
- Global Logistics Coordination for Hastelloy C22 Tee shipments to the UAE, Saudi Arabia, Qatar, Oman, Africa, Singapore, Europe and other destinations.
Key Features of Hastelloy C22 Tee
- Nickel-Chromium-Molybdenum-Tungsten Alloy Construction – Manufactured from Hastelloy C22 for demanding corrosion-resistant applications.
- Excellent Corrosion Resistance – Provides broad resistance to many aggressive chemical environments.
- Excellent Pitting Resistance – Suitable for applications where localized corrosion is a concern.
- Excellent Crevice Corrosion Resistance – Provides reliable performance in environments prone to crevice corrosion.
- Good Resistance to Stress Corrosion Cracking – Offers useful resistance in many demanding process environments.
- Resistance to Oxidizing Environments – Suitable for selected oxidizing chemical service conditions.
- Resistance to Reducing Environments – Provides useful performance across many reducing process environments.
- Strong Chloride Resistance – Suitable for selected chloride-containing process environments.
- Good Resistance to Aggressive Chemicals – Can be considered for applications involving severe chemical media.
- Reliable Butt-Weld Connection – Provides a permanent welded connection for industrial piping systems.
- Equal Tee Configuration – Available where the run and branch require the same nominal size.
- Reducing Tee Configuration – Available where a smaller branch connection is required.
- Efficient Branch Connection – Provides a practical connection for branching process or piping lines.
- Wide Size Availability – Available in different nominal sizes and outside diameters.
- Multiple Wall Thicknesses – Different schedules and customized wall thicknesses can be supplied.
- Good Weldability – Suitable for fabrication using qualified welding procedures.
- Good Fabrication Characteristics – Can be processed using appropriate industrial fabrication practices.
- Solution-Annealed Options – Can be supplied in applicable heat-treated conditions.
- Chemical Processing Applications – Suitable for aggressive chemical process piping.
- Petrochemical Applications – Can be considered for selected petrochemical process systems.
- Pollution-Control Applications – Suitable for selected pollution-control and flue-gas systems.
- Waste Treatment Applications – Can be considered for selected corrosive waste-treatment systems.
- Pharmaceutical Applications – Suitable for selected corrosion-sensitive process equipment.
- Power Generation Applications – Can be used in selected power-generation process systems.
- High-Temperature Service – Provides useful corrosion and mechanical performance at elevated temperatures within applicable design limits.
- Custom Branch Dimensions – Branch sizes and configurations can be supplied according to project requirements.
- Multiple Surface Options – Mill finish or other specified finishes can be supplied.
- Reliable Material Traceability – Material identification and relevant certificates can be supplied according to order requirements.
- Quality Testing Available – Chemical, mechanical, dimensional, visual and other specified inspections can be arranged.
- Export-Ready Material – Tees can be suitably packed for handling, storage and international transportation.
- Global Hastelloy C22 Tee Exporter – METALX NICKEL & ALLOYS supplies Hastelloy C22 Tees to international buyers, distributors, traders, stockholders and industrial end users.
| Specification | Hastelloy C22 Tee Details |
|---|---|
| Product Name | Hastelloy C22 Tee |
| Material Grade | Hastelloy C22 |
| UNS Designation | N06022 |
| Material Type | Nickel-Chromium-Molybdenum-Tungsten Alloy |
| Material Standard | ASTM B366 / ASME SB366, where applicable |
| Dimensional Standard | ASME B16.9, where applicable |
| Tee Type | Equal Tee / Reducing Tee |
| Connection Type | Butt Weld |
| Size | As per applicable standard or customer specification |
| Wall Thickness | Different schedules and customized thicknesses |
| Branch Size | Equal or reducing branch sizes as required |
| Manufacturing | Wrought / Formed, as applicable |
| Surface Finish | Mill Finish or customer-specified finish |
| Heat Treatment | Solution Annealed as applicable |
| End Preparation | Bevelled Butt-Weld Ends |
| Testing | Chemical, mechanical, dimensional, visual and other specified inspections |
| Documentation | MTC, inspection reports and relevant quality documents as required |
| Customization | Size, thickness, branch dimensions, finish, testing and documentation |
| Packing | Export-worthy packing suitable for safe international transportation |
| Applications | Chemical Processing, Petrochemical, Pollution Control, Pharmaceutical, Waste Treatment, Power Generation and Corrosive Process Piping |
