Titanium Grade 5 Cross
| Parameter | Titanium Grade 5 Cross Details |
|---|---|
| Product Name | Titanium Grade 5 Cross |
| Material Grade | Titanium Grade 5 / Ti-6Al-4V |
| UNS Number | R56400 |
| Werkstoff Number | 3.7165 / 3.7164 |
| Alloy Type | Alpha-Beta Titanium Alloy |
| Product Standard | ASTM B363 / ASME SB363 |
| Dimensional Standard | ASME B16.9 |
| Cross Configuration | Equal Cross / Reducing Cross |
| Branch Arrangement | Four-Way / Reduced Branch |
| Nominal Size | 1/2″ to 48″ |
| Construction | Seamless / Welded / Fabricated |
| Wall Thickness | SCH 5S–SCH 160 / Custom |
| End Connection | Butt Weld |
| End Preparation | Beveled / Plain / Customized |
| Heat Treatment | As per applicable specification |
| Surface Finish | Mill / Pickled / Polished |
| Aluminium | Approx. 5.5–6.75% |
| Vanadium | Approx. 3.5–4.5% |
| Titanium | Balance |
| Tensile Strength | Approx. 895 MPa minimum |
| Yield Strength | Approx. 825 MPa minimum |
| Elongation | Approx. 10% minimum |
| Density | Approx. 4.43 g/cm³ |
| Strength-to-Weight Ratio | Excellent |
| Corrosion Resistance | Excellent resistance to seawater, chlorides and many chemical environments |
| Weldability | Good with proper inert-gas shielding |
| Inspection | PMI / Visual / Dimensional / Mechanical / NDT |
| Certification | EN 10204 3.1 / 3.2 |
| Traceability | Heat Number / Batch Identification |
| Customization | Branch sizes, thickness, dimensions and special geometry |
| Supply | Domestic & Worldwide Export |
| Applications | Aerospace, Chemical Processing, Marine, Oil & Gas, Heat Exchangers, Power Generation and Process Piping |
Titanium Grade 5 Cross – Equal & Reducing Sizes
| Run Size | Branch Size | Cross Type | Run OD | Branch OD |
|---|---|---|---|---|
| 1/2″ | 1/2″ | Equal Cross | 21.34 mm | 21.34 mm |
| 3/4″ | 3/4″ | Equal Cross | 26.67 mm | 26.67 mm |
| 1″ | 1″ | Equal Cross | 33.40 mm | 33.40 mm |
| 1-1/4″ | 1-1/4″ | Equal Cross | 42.16 mm | 42.16 mm |
| 1-1/2″ | 1-1/2″ | Equal Cross | 48.26 mm | 48.26 mm |
| 2″ | 2″ | Equal Cross | 60.33 mm | 60.33 mm |
| 2-1/2″ | 2-1/2″ | Equal Cross | 73.03 mm | 73.03 mm |
| 3″ | 3″ | Equal Cross | 88.90 mm | 88.90 mm |
| 4″ | 4″ | Equal Cross | 114.30 mm | 114.30 mm |
| 6″ | 6″ | Equal Cross | 168.28 mm | 168.28 mm |
| 8″ | 8″ | Equal Cross | 219.08 mm | 219.08 mm |
| 10″ | 10″ | Equal Cross | 273.05 mm | 273.05 mm |
| 12″ | 12″ | Equal Cross | 323.85 mm | 323.85 mm |
| 2″ | 1″ | Reducing Cross | 60.33 mm | 33.40 mm |
| 3″ | 2″ | Reducing Cross | 88.90 mm | 60.33 mm |
| 4″ | 2″ | Reducing Cross | 114.30 mm | 60.33 mm |
| 4″ | 3″ | Reducing Cross | 114.30 mm | 88.90 mm |
| 6″ | 4″ | Reducing Cross | 168.28 mm | 114.30 mm |
| 8″ | 6″ | Reducing Cross | 219.08 mm | 168.28 mm |
| 10″ | 8″ | Reducing Cross | 273.05 mm | 219.08 mm |
| 12″ | 10″ | Reducing Cross | 323.85 mm | 273.05 mm |
Titanium Grade 5 Cross – Size & Schedule Range
| NPS | Outside Diameter | Typical Schedule | Configuration |
|---|---|---|---|
| 1/2″ | 21.34 mm | SCH 5S–XXS | Equal / Reducing |
| 3/4″ | 26.67 mm | SCH 5S–XXS | Equal / Reducing |
| 1″ | 33.40 mm | SCH 5S–XXS | Equal / Reducing |
| 1-1/4″ | 42.16 mm | SCH 5S–XXS | Equal / Reducing |
| 1-1/2″ | 48.26 mm | SCH 5S–XXS | Equal / Reducing |
| 2″ | 60.33 mm | SCH 5S–XXS | Equal / Reducing |
| 2-1/2″ | 73.03 mm | SCH 5S–XXS | Equal / Reducing |
| 3″ | 88.90 mm | SCH 5S–XXS | Equal / Reducing |
| 4″ | 114.30 mm | SCH 5S–XXS | Equal / Reducing |
| 6″ | 168.28 mm | SCH 5S–XXS | Equal / Reducing |
| 8″ | 219.08 mm | SCH 5S–XXS | Equal / Reducing |
| 10″ | 273.05 mm | SCH 5S–XXS | Equal / Reducing |
| 12″ | 323.85 mm | SCH 5S–XXS | Equal / Reducing |
| 14″ | 355.60 mm | SCH 5S–XXS | Equal / Reducing |
| 16″ | 406.40 mm | SCH 5S–XXS | Equal / Reducing |
| 18″ | 457.20 mm | SCH 5S–XXS | Equal / Reducing |
| 20″ | 508.00 mm | SCH 5S–XXS | Equal / Reducing |
| 24″ | 609.60 mm | SCH 5S–XXS | Equal / Reducing |
| 30″–48″ | 762–1219.20 mm | As Required | Equal / Reducing |
Titanium Grade 5 Cross – Manufacturing & Quality Details
| Feature | Available Options / Details |
|---|---|
| Cross Pattern | Equal / Reducing |
| Production Process | Hot Formed / Cold Formed / Seamless / Welded |
| Size Range | 1/2″–48″ |
| Branch Size | Equal / Reduced / Custom |
| Wall Thickness | Standard / Heavy Wall / Custom |
| Connection | Butt Weld |
| End Preparation | Beveled / Plain / Special |
| Surface Treatment | Mill / Pickled / Polished |
| Heat Treatment | As Required by Specification |
| Welding Protection | High-Purity Inert Gas Shielding |
| Material Verification | PMI / Chemical Analysis |
| Mechanical Testing | Tensile / Yield / Elongation |
| Dimensional Inspection | OD / Thickness / Branch Alignment / Squareness |
| NDT | UT / RT / PT as specified |
| Weld Inspection | As per applicable welding specification |
| Documentation | MTC / EN 10204 3.1 / 3.2 |
| Traceability | Heat Number / Batch Identification |
| Third-Party Inspection | Available as required |
| Packing | Export-Grade Wooden Cases / Bundles |
| Custom Manufacturing | Special branch sizes, thicknesses and non-standard geometries |
Why Should You Buy Titanium Grade 5 Cross from Metalx Nickel & Alloys?
- Experienced Titanium Grade 5 Cross Supplier & Exporter serving international buyers, distributors, EPC contractors, stockholders and industrial end users.
- 20+ Years of Alloy Industry Experience in supplying high-performance titanium and specialty-alloy products to customers across the UAE, Saudi Arabia, Africa and other global markets.
- Specialized Titanium Grade 5 Exporter offering Titanium Grade 5 / Ti-6Al-4V / UNS R56400 Cross Fittings for demanding engineering applications.
- High-Strength Titanium Expertise for applications requiring an excellent combination of strength, corrosion resistance and low material density.
- Global Sourcing Network with access to reputed titanium mills, manufacturers and approved stockholders across Europe, USA, Japan and other major supply markets.
- Wide Titanium Product Range including Titanium Grade 1, Grade 2, Grade 5 and other titanium products, subject to requirements.
- Ready Stock Availability for selected Titanium Grade 5 Cross sizes, subject to current stock and availability.
- Custom Titanium Grade 5 Cross Supply according to customer drawings, size, schedule, wall thickness and branch dimensions.
- Equal & Reducing Cross Supply for standard and specialized piping requirements.
- ASTM / ASME Specification Supply according to applicable requirements, including ASTM B363 / ASME SB363, where applicable.
- ASME B16.9 Dimensional Compliance can be supplied where applicable to the fitting configuration.
- MTC with Quotation – Material Test Certificates and relevant technical documentation can be provided with export quotations and orders.
- EN 10204 3.1 / 3.2 Certification available according to the purchase order, project specification and inspection requirements.
- PMI Testing Support for positive material identification where required.
- Third-Party Inspection Support can be coordinated through approved inspection agencies for international export orders.
- Chemical, Mechanical & Dimensional Testing can be arranged according to applicable standards and customer specifications.
- Visual & Hardness Testing Support can be arranged where required by the applicable specification or purchase order.
- NDT Support including applicable ultrasonic or radiographic examination where specified.
- Custom Surface Finish can be arranged according to the applicable specification.
- Export-Ready Packing designed to protect Titanium Grade 5 Cross Fittings during handling, storage and international transportation.
- Worldwide Titanium Grade 5 Cross Exporter serving buyers across the Middle East, Africa, Asia, Europe and other international markets.
- Competitive Export Pricing for bulk quantities, project orders, distributors, importers, traders and international stockholders.
- Titanium Grade 5 Cross Export Support for aerospace suppliers, EPC contractors, engineering companies, oil & gas facilities, chemical plants, marine projects, petrochemical plants and specialized industrial buyers.
- Technical Support from Export Enquiry to Shipment covering grade, size, schedule, wall thickness, branch dimensions, testing, certification and packing requirements.
- Material Traceability with appropriate identification, certification and quality documentation for export projects.
- Data Sheets & Technical Documentation can be supplied according to customer requirements and project specifications.
- Global Logistics Coordination for Titanium Grade 5 Cross shipments to the UAE, Saudi Arabia, Qatar, Oman, Africa, Singapore, Europe and other destinations.
Key Features of Titanium Grade 5 Cross
- Ti-6Al-4V Titanium Alloy Construction – Manufactured from Titanium Grade 5 for high-performance piping and engineering applications.
- High Strength-to-Weight Ratio – Provides excellent mechanical strength while maintaining relatively low material density.
- Excellent Corrosion Resistance – Offers strong resistance to many corrosive environments.
- Good Seawater Resistance – Suitable for selected marine and seawater-service applications.
- High Mechanical Strength – Suitable for demanding industrial and engineering systems.
- Good Fatigue Performance – Useful for applications involving appropriate cyclic loading.
- Alpha-Beta Titanium Alloy – Provides a balanced combination of strength, toughness and corrosion resistance.
- Four-Way Connection Design – Provides multiple connection points within a piping network.
- Equal Cross Configuration – Suitable where all connection points require the same nominal size.
- Reducing Cross Configuration – Suitable where one or more connections require different sizes.
- Multi-Directional Flow Connection – Allows several process lines to connect through a single fitting.
- Smooth Branch Transitions – Supports practical integration of multiple branch lines.
- Reliable Butt-Weld Connection – Provides a permanent welded connection when properly fabricated.
- Wide Size Availability – Available in different nominal pipe sizes and outside diameters.
- Multiple Wall Thicknesses – Different schedules and customized thicknesses can be supplied.
- Wrought / Formed Construction – Manufactured according to applicable titanium fitting requirements.
- Seamless & Welded Options – Configuration can be supplied depending on size and specification.
- Good Fabrication Characteristics – Suitable for controlled forming and fabrication processes.
- Low Material Density – Helps reduce component weight compared with many conventional high-strength alloys.
- Aerospace Applications – Suitable for selected aerospace and high-performance engineering applications.
- Oil & Gas Applications – Can be considered for selected oil & gas piping and process systems.
- Chemical Processing Applications – Useful for selected corrosive process environments.
- Petrochemical Applications – Suitable for selected petrochemical equipment and piping.
- Marine Applications – Suitable for selected marine and seawater-service systems.
- Power Generation Applications – Can be considered for selected power-generation systems.
- Heat Exchanger Applications – Useful for selected heat-transfer equipment.
- Desalination Applications – Suitable for selected seawater and desalination equipment.
- Industrial Process Piping – Suitable where high strength, corrosion resistance and weight efficiency are important.
- Custom Branch Dimensions – Branch sizes and configurations can be supplied according to customer drawings.
- Multiple Surface Options – Mill finish, pickled or other specified finishes can be supplied.
- PMI Verification – Positive Material Identification can be arranged where required.
- Material Traceability – Material identification and relevant certification can be supplied.
- Quality Testing Available – Chemical, mechanical, dimensional, visual, PMI and other specified inspections can be arranged.
- Export-Ready Material – Cross fittings can be suitably packed for handling, storage and international transportation.
- Global Titanium Grade 5 Cross Exporter – METALX NICKEL & ALLOYS supplies Titanium Grade 5 Cross Fittings to international buyers, distributors, traders, stockholders and industrial end users.
| Specification | Titanium Grade 5 Cross Details |
|---|---|
| Product Name | Titanium Grade 5 Cross |
| Material Grade | Titanium Grade 5 / Ti-6Al-4V |
| UNS Designation | R56400 |
| Werkstoff Number | 3.7165 / 3.7164 |
| Material Type | Alpha-Beta Titanium Alloy |
| Material Standard | ASTM B363 / ASME SB363, where applicable |
| Dimensional Standard | ASME B16.9, where applicable |
| Cross Type | Equal Cross / Reducing Cross |
| Connection Type | Butt Weld |
| Size | As per applicable standard or customer specification |
| Wall Thickness | Different schedules and customized thicknesses |
| Branch Size | Equal or reducing branch sizes as required |
| Manufacturing | Wrought / Formed, as applicable |
| Configuration | Seamless / Welded, depending on size and specification |
| End Preparation | Bevelled Ends for Butt Welding |
| Heat Treatment | As per applicable specification |
| Surface Finish | Mill Finish, Pickled or customer-specified finish |
| Testing | Chemical, mechanical, dimensional, visual, PMI and other specified inspections |
| Documentation | MTC, inspection reports and relevant quality documents as required |
| Customization | Size, thickness, schedule, branch dimensions, finish, testing and documentation |
| Packing | Export-worthy packing suitable for safe international transportation |
| Applications | Aerospace, Oil & Gas, Chemical Processing, Marine, Petrochemical, Power Generation and Industrial Piping |
What is a Titanium Grade 5 Cross?
A Titanium Grade 5 Cross is a Ti-6Al-4V titanium alloy butt-weld fitting with four connection points, used to create multiple branches in high-performance piping systems.
What is Titanium Grade 5 commonly known as?
Titanium Grade 5 is commonly known as Ti-6Al-4V.
Which industries does MetalX Nickel & Alloys serve?
Our alloy products are suitable for Oil & Gas, Chemical Processing, Petrochemical, Power Generation, Marine, Aerospace, Pharmaceutical, Engineering, Fabrication, and other critical industrial applications.
What makes MetalX Nickel & Alloys different from other alloy suppliers?
Our focus on quality, technical reliability, product consistency, customer service, and application-focused solutions helps us provide dependable alloy materials for challenging industrial requirements.
What is the Werkstoff Number of Titanium Grade 5?
Commonly referenced Werkstoff Numbers include 3.7165 / 3.7164, depending on the applicable product designation and condition.
Why are Nickel Alloys important for industrial applications?
Nickel alloys offer excellent properties such as corrosion resistance, high-temperature strength, oxidation resistance, durability, and mechanical performance, making them suitable for demanding operating environments.
