Incoloy 800 Cross
| Specification | Incoloy 800 Cross Details |
|---|---|
| Product Name | Incoloy 800 Cross |
| Material Grade | Incoloy 800 / Alloy 800 |
| UNS Designation | UNS N08800 |
| Werkstoff Number | W.Nr. 1.4876 |
| Material Type | Nickel-Chromium-Iron Alloy |
| Chemical Composition | Nickel 30–35%, Chromium 19–23%, Iron Balance, Aluminium 0.15–0.60%, Titanium 0.15–0.60%, Carbon 0.10% max |
| Manufacturing Type | Seamless / Welded / Hot Formed / Cold Formed |
| Fitting Standard | ASTM B366 / ASME SB366 |
| Dimensional Standard | ASME B16.9 |
| Cross Type | Equal Cross / Reducing Cross |
| Size | NPS 1/2 to NPS 48 or as required |
| Outside Diameter | As per ASME B16.9 / Customer Requirement |
| Wall Thickness | SCH 5S, 10S, 10, 40S, 40, 80S, 80, 100, 120, 140, 160, XXS or as required |
| Branch Size | Equal / Reduced Branch as specified |
| End Type | Butt Weld / Beveled End / Customized |
| Surface Finish | Mill Finish / Pickled / Annealed / Polished / Customized |
| Heat Treatment | Solution Annealed / Stabilized as applicable |
| MTC | EN 10204 3.1 / 3.2 |
| Testing | Chemical, Mechanical, Dimensional, Visual, Hydrostatic, PMI and NDT as specified |
| Tensile Strength | Minimum approximately 500 MPa |
| Yield Strength | Minimum approximately 170 MPa |
| Elongation | Minimum approximately 30% |
| Density | Approximately 7.94 g/cm³ |
| Melting Range | Approximately 1350–1400°C |
| Corrosion Resistance | Excellent resistance to oxidation, carburization and nitridation at elevated temperatures |
| High-Temperature Resistance | Excellent resistance to high-temperature oxidation and thermal cycling |
| Chemical Resistance | Good resistance to many aqueous and corrosive environments |
| Welding | Good weldability using suitable Incoloy 800-compatible welding procedures |
| Filler Metal | ERNiCr-3 / ENiCrFe-2 |
| Welding Electrode | ENiCrFe-2 |
| Available Form | Equal Cross / Reducing Cross |
| Customization | Size, Schedule, Branch Size, End Preparation, Finish, Testing and Documentation |
| Origin | European / American / Japanese / Korean and other approved origins |
| Export Supply | Worldwide Export Supply |
| Exporter Support | Technical specification, inspection, certification, export packing and international shipment coordination |
| Applications | Heat Treatment Equipment, Petrochemical, Chemical Processing, Power Generation, Heat Exchangers, Furnace Components, Industrial Heating Equipment and Process Industries |
Incoloy 800 Cross – Standard Dimensions
| NPS | Outside Diameter (mm) | Outside Diameter (in.) | Typical Schedule Range |
|---|---|---|---|
| 1/2″ | 21.34 | 0.840 | SCH 5S–XXS |
| 3/4″ | 26.67 | 1.050 | SCH 5S–XXS |
| 1″ | 33.40 | 1.315 | SCH 5S–XXS |
| 1-1/4″ | 42.16 | 1.660 | SCH 5S–XXS |
| 1-1/2″ | 48.26 | 1.900 | SCH 5S–XXS |
| 2″ | 60.33 | 2.375 | SCH 5S–XXS |
| 2-1/2″ | 73.03 | 2.875 | SCH 5S–XXS |
| 3″ | 88.90 | 3.500 | SCH 5S–XXS |
| 4″ | 114.30 | 4.500 | SCH 5S–XXS |
| 5″ | 141.30 | 5.563 | SCH 5S–XXS |
| 6″ | 168.28 | 6.625 | SCH 5S–XXS |
| 8″ | 219.08 | 8.625 | SCH 5S–XXS |
| 10″ | 273.05 | 10.750 | SCH 5S–XXS |
| 12″ | 323.85 | 12.750 | SCH 5S–XXS |
| 14″ | 355.60 | 14.000 | SCH 5S–XXS |
| 16″ | 406.40 | 16.000 | SCH 5S–XXS |
| 18″ | 457.20 | 18.000 | SCH 5S–XXS |
| 20″ | 508.00 | 20.000 | SCH 5S–XXS |
| 24″ | 609.60 | 24.000 | SCH 5S–XXS |
| 30″ | 762.00 | 30.000 | As Required |
| 36″ | 914.40 | 36.000 | As Required |
| 42″ | 1066.80 | 42.000 | As Required |
| 48″ | 1219.20 | 48.000 | As Required |
Incoloy 800 Cross – Equal & Reducing Cross Sizes
| Run Size | Branch Size | Cross Type | Outside Diameter |
|---|---|---|---|
| 1/2″ | 1/2″ | Equal Cross | 21.34 mm |
| 3/4″ | 3/4″ | Equal Cross | 26.67 mm |
| 1″ | 1″ | Equal Cross | 33.40 mm |
| 1-1/4″ | 1-1/4″ | Equal Cross | 42.16 mm |
| 1-1/2″ | 1-1/2″ | Equal Cross | 48.26 mm |
| 2″ | 2″ | Equal Cross | 60.33 mm |
| 2-1/2″ | 2-1/2″ | Equal Cross | 73.03 mm |
| 3″ | 3″ | Equal Cross | 88.90 mm |
| 4″ | 4″ | Equal Cross | 114.30 mm |
| 6″ | 6″ | Equal Cross | 168.28 mm |
| 8″ | 8″ | Equal Cross | 219.08 mm |
| 10″ | 10″ | Equal Cross | 273.05 mm |
| 12″ | 12″ | Equal Cross | 323.85 mm |
| 2″ | 1″ | Reducing Cross | 60.33 / 33.40 mm |
| 3″ | 2″ | Reducing Cross | 88.90 / 60.33 mm |
| 4″ | 2″ | Reducing Cross | 114.30 / 60.33 mm |
| 4″ | 3″ | Reducing Cross | 114.30 / 88.90 mm |
| 6″ | 4″ | Reducing Cross | 168.28 / 114.30 mm |
| 8″ | 6″ | Reducing Cross | 219.08 / 168.28 mm |
| 10″ | 8″ | Reducing Cross | 273.05 / 219.08 mm |
| 12″ | 10″ | Reducing Cross | 323.85 / 273.05 mm |
Incoloy 800 Cross – Size & Type Chart
| Size Range | Cap Type | Available Finish | Supply Condition | End Connection |
|---|---|---|---|---|
| 1/2″–2″ | Seamless / Welded | Bright / Pickled / Polished | Solution Annealed / Age Hardened | Butt Weld |
| 2-1/2″–4″ | Seamless / Welded | Mill / Pickled / Polished | Solution Annealed / Age Hardened | Butt Weld |
| 5″–8″ | Seamless / Welded | Mill / Pickled / Machined | Solution Annealed / Age Hardened | Butt Weld |
| 10″–12″ | Welded / Formed | Mill / Pickled / Machined | Solution Annealed / Age Hardened | Butt Weld |
| 14″–18″ | Welded / Formed | Mill / Machined | Solution Annealed / Age Hardened | Butt Weld |
| 20″–24″ | Welded / Formed | Mill / Machined | Solution Annealed / Age Hardened | Butt Weld |
| 30″–36″ | Welded / Custom Formed | Mill / Machined | Solution Annealed / Age Hardened | Butt Weld |
| 42″–48″ | Welded / Custom Formed | Mill / Machined | Solution Annealed / Age Hardened | Butt Weld |
Why Should You Buy Incoloy 800 Cross from Metalx Nickel & Alloys?
- Experienced Incoloy 800 Cross Supplier & Exporter serving international buyers, distributors, EPC contractors, stockholders and industrial end users.
- 20+ Years of Nickel Alloy Industry Experience in supplying corrosion-resistant and high-temperature alloy products to customers across the UAE, Saudi Arabia, Africa and other global markets.
- Specialized Incoloy 800 Exporter offering Incoloy 800 / Alloy 800 / UNS N08800 Cross Fittings for demanding high-temperature and industrial applications.
- Global Sourcing Network with access to reputed nickel alloy mills, manufacturers and approved stockholders across Europe, USA, Japan and other major supply markets.
- Wide Nickel Alloy Fittings Range including Incoloy 800, Incoloy 800H, Incoloy 800HT, Incoloy 825, Inconel, Monel and Hastelloy fittings.
- Ready Stock Availability for selected Incoloy 800 Cross sizes, subject to current stock and availability.
- Custom Incoloy 800 Cross Supply according to customer drawings, size, schedule, wall thickness and branch dimensions.
- Equal & Reducing Cross Supply for standard and specialized industrial piping requirements.
- ASTM / ASME Specification Supply according to applicable requirements, including ASTM B366 / ASME SB366, where applicable.
- ASME B16.9 Dimensional Compliance can be supplied where applicable to the fitting configuration.
- MTC with Quotation – Material Test Certificates and relevant technical documentation can be provided with export quotations and orders.
- EN 10204 3.1 / 3.2 Certification available according to the purchase order, project specification and inspection requirements.
- Third-Party Inspection Support can be coordinated through approved inspection agencies for international export orders.
- Chemical, Mechanical & Dimensional Testing can be arranged according to applicable standards and customer specifications.
- Visual & Hardness Testing Support can be arranged where required by the applicable specification or purchase order.
- Custom Surface Finish – Mill finish, pickled or other specified finishes can be supplied according to requirements.
- Export-Ready Packing designed to protect Incoloy 800 Cross Fittings during handling, storage and international transportation.
- Worldwide Incoloy 800 Cross Exporter serving buyers across the Middle East, Africa, Asia, Europe and other international markets.
- Competitive Export Pricing for bulk quantities, project orders, distributors, importers, traders and international stockholders.
- Incoloy 800 Cross Export Support for EPC contractors, engineering companies, chemical plants, petrochemical facilities, power-generation companies, heat-exchanger manufacturers and specialized industrial buyers.
- Technical Support from Export Enquiry to Shipment covering grade, size, schedule, wall thickness, branch dimensions, heat treatment, testing, certification and packing requirements.
- Material Traceability with appropriate identification, certification and quality documentation for export projects.
- Data Sheets & Technical Documentation can be supplied according to customer requirements and project specifications.
- Global Logistics Coordination for Incoloy 800 Cross shipments to the UAE, Saudi Arabia, Qatar, Oman, Africa, Singapore, Europe and other destinations.
Key Features of Incoloy 800 Cross
- Nickel-Iron-Chromium Alloy Construction – Manufactured from Incoloy 800 for high-temperature and corrosion-resistant applications.
- Good High-Temperature Performance – Suitable for selected elevated-temperature service conditions.
- Good Oxidation Resistance – Provides resistance to oxidation in many high-temperature environments.
- Good Carburization Resistance – Can be considered for selected carburizing service conditions.
- Good Corrosion Resistance – Provides useful resistance to many industrial process environments.
- Reliable Butt-Weld Connection – Provides a permanent welded connection for industrial piping systems.
- Four-Way Branch Configuration – Provides multiple connection points for selected piping arrangements.
- Equal Cross Configuration – Suitable where the run and branches require the same nominal size.
- Reducing Cross Configuration – Suitable where one or more branch connections require different sizes.
- Efficient Multi-Direction Connection – Useful for selected piping layouts requiring multiple flow paths.
- Wide Size Availability – Available in different nominal sizes and outside diameters.
- Multiple Wall Thicknesses – Different schedules and customized thicknesses can be supplied.
- Good Mechanical Strength – Provides useful strength under elevated-temperature service.
- Good Fabrication Characteristics – Can be formed, welded and machined using appropriate industrial procedures.
- Solution-Annealed Options – Can be supplied in applicable heat-treated conditions.
- Heat Exchanger Applications – Suitable for selected heat-transfer equipment.
- Furnace Applications – Can be considered for industrial furnace systems.
- Petrochemical Applications – Suitable for selected petrochemical processing systems.
- Chemical Processing Applications – Can be considered for selected chemical process equipment.
- Power Generation Applications – Useful in selected high-temperature power-generation systems.
- Heating Equipment Applications – Suitable for selected heating and thermal-processing equipment.
- High-Temperature Piping – Designed for applications requiring temperature and corrosion performance.
- Custom Branch Dimensions – Branch sizes and configurations can be supplied according to project requirements.
- Multiple Surface Options – Mill finish, pickled or other specified finishes can be supplied.
- Material Traceability – Material identification and relevant certificates can be supplied as required.
- Quality Testing Available – Chemical, mechanical, dimensional, visual and other specified inspections can be arranged.
- Export-Ready Material – Cross fittings can be suitably packed for handling and international transportation.
- Global Incoloy 800 Cross Exporter – METALX NICKEL & ALLOYS supplies Incoloy 800 Cross Fittings to international buyers, distributors, traders, stockholders and industrial end users.
| Specification | Incoloy 800 Cross Details |
|---|---|
| Product Name | Incoloy 800 Cross |
| Material Grade | Incoloy 800 / Alloy 800 |
| UNS Designation | N08800 |
| Werkstoff Number | 1.4876 |
| Material Type | Nickel-Iron-Chromium Alloy |
| Material Standard | ASTM B366 / ASME SB366, where applicable |
| Dimensional Standard | ASME B16.9, where applicable |
| Cross Type | Equal Cross / Reducing Cross |
| Connection Type | Butt Weld |
| Size | As per applicable standard or customer specification |
| Wall Thickness | Different schedules and customized thicknesses |
| Branch Size | Equal or reducing branch sizes as required |
| Manufacturing | Wrought / Formed, as applicable |
| Surface Finish | Mill Finish, Pickled or customer-specified finish |
| Heat Treatment | Solution Annealed as applicable |
| End Preparation | Bevelled Ends for Butt Welding |
| Testing | Chemical, mechanical, dimensional, visual and other specified inspections |
| Documentation | MTC, inspection reports and relevant quality documents as required |
| Customization | Size, thickness, branch dimensions, finish, testing and documentation |
| Packing | Export-worthy packing suitable for safe international transportation |
| Applications | Heat Exchangers, Petrochemical Plants, Chemical Processing, Industrial Furnaces, Power Generation, Heating Equipment and High-Temperature Piping |
