Hastelloy C276 Elbow
| Specification Hastelloy C276 Elbow Details | |
|---|---|
| Product Name | Hastelloy C276 Elbow |
| Material Grade | Hastelloy C276 / Alloy C276 |
| UNS Designation | UNS N10276 |
| Werkstoff Number | W.Nr. 2.4819 |
| Material Type | Nickel-Chromium-Molybdenum-Tungsten Alloy |
| Chemical Composition | Nickel Balance, Chromium 14.5–16.5%, Molybdenum 15–17%, Tungsten 3–4.5%, Iron 4–7%, Cobalt 2.5% max, Carbon 0.01% max, Vanadium 0.35% max |
| Manufacturing Type | Seamless / Welded / Hot Formed / Cold Formed |
| Fitting Standard | ASTM B366 / ASME SB366 |
| Dimensional Standard | ASME B16.9 |
| Socket-Weld / Threaded Standard | ASME B16.11, where applicable |
| Elbow Type | Long Radius / Short Radius |
| Elbow Angle | 45° / 90° / 180° / Customized |
| Radius | 1.5D Long Radius / 1D Short Radius / Customized Radius |
| Size | NPS 1/2 to NPS 48 or as required |
| Outside Diameter | As per ASME B16.9 / Customer Requirement |
| Wall Thickness | SCH 5S, 10S, 10, 40S, 40, 80S, 80, 100, 120, 140, 160, XXS or as required |
| End Type | Plain End / Beveled End / Customized |
| Surface Finish | Mill Finish / Pickled / Annealed / Polished / Customized |
| Heat Treatment | Solution Annealed / Rapidly Quenched as applicable |
| MTC | EN 10204 3.1 / 3.2 |
| Testing | Chemical, Mechanical, Dimensional, Visual, Hydrostatic, PMI and NDT as specified |
| Tensile Strength | Minimum approximately 690 MPa |
| Yield Strength | Minimum approximately 283 MPa |
| Elongation | Minimum approximately 40% |
| Density | Approximately 8.89 g/cm³ |
| Melting Range | Approximately 1325–1370°C |
| Corrosion Resistance | Excellent resistance to pitting, crevice corrosion, stress-corrosion cracking and aggressive oxidizing/reducing environments |
| High-Temperature Resistance | Excellent resistance to oxidation and corrosive environments at elevated temperatures |
| Chemical Resistance | Excellent resistance to wet chlorine, ferric chloride, sulfuric acid, hydrochloric acid and other severe chemical environments |
| Welding | Excellent weldability using suitable Hastelloy C276-compatible welding procedures |
| Filler Metal | ERNiCrMo-4 / Alloy C276 compatible filler |
| Welding Electrode | ENiCrMo-4 |
| Available Form | 45° Elbow / 90° Elbow / 180° Return / Custom Elbow |
| Customization | Size, Schedule, Angle, Radius, Length, End Preparation, Finish, Testing and Documentation |
| Origin | European / American / Japanese / Korean and other approved origins |
| Export Supply | Worldwide Export Supply |
| Exporter Support | Technical specification, inspection, certification, export packing and international shipment coordination |
| Applications | Chemical Processing, Petrochemical, Oil & Gas, Pharmaceutical, Pollution Control, Waste Treatment, FGD Systems, Marine, Power Generation and Process Industries |
